Product Center

Yugong Machinery mainly focuses on the manufacturing of processing equipment for roll packaging materials. The products it produces are widely used in the paper product packaging industry and the printing and packaging industry. Our main products include: fully automatic high-speed slitting machines, A3/A4 paper cutting and packaging integrated machines, automatic finishing and cross-cutting machines, etc. Please contact us for specific product parameters.
YGA-A4

A4 Paper Slitting Machine

Max.width of cutting: 1100mm
Max diameter of material: φ1400mm
Min.width of cutting: A3/A4mm
Speed: ≤200times/min
Total Power: 12kw
Weight: 4500kg
Overall dimension：8600x1800x1350mm
It is suitable for cutting different office paper, high-gloss photo paper, and paper-plastic composite roll packaging materials.
YGZ-1400

Fully Automatic High-speed Cross-cutting Machine

Max.width of cutting: 1400mm
Max diameter of material: φ1400mm
Cutting Length: 300-1200mm
Speed: ≤30-200times/min
Total Power: 10kw
Weight: 5000kg
Overall dimension：5800×3200×2000mm
Suitable for horizontal and vertical cutting of various large roll packaging materials.
YGA-A4

Fully Automatic High-speed Slitting Machine

Max.width of cutting: 1600mm
Max diameter of material: φ1400mm
Min. Rewind Web Width: 30mm
Speed: 30-500 m/min
Total Power: 26 kw
Weight: 4500kg
Overall dimension：4500×3200×1950mm
It is suitable for the strip rewinding of a variety of web packaging materials, such as offset paper, copper paper, laminated paper, white cardboard and other roll packaging materials.

Product Advantages

thresscenterUse PLC to control fixed length, automatic counting and alarm shutdown functions.
The unwinding adopts automatic feeding, saving labor.
The winding is controlled by servo motor, which is high-speed, efficient and stable.
Round knife/flat knife slitting structure, waste edge fan automatically removes.
Hydraulic automatic unloading saves labor.
With high-precision cutting and low noise.

Cuttable Material

A4 paper, straw paper, coated paper, laminated paper, white cardboard, non-woven fabric, mica tape, insulation materials, leather, PVC film, tape, self-adhesive, aluminum foil.
Paper
Foil
Film
Cloth
Self-adhesive
Our machines can cut a variety of raw materials, have a variety of configurations to choose from, and can also support customized services.
